| 40*40*07MM | ||||||||||||
| Model | Bearing | Rated Voltage | Startup Voltage | Current | Power | Speed | Air Flow | Static Pressure | Noise | |||
| Part NO. | Function | System | VDC | VDC | A | W | RPM | M3/min | CFM | mmH2O | INH2O | dBA |
| HBH0405HQ | Hydraulic | 5 | 4.0 | 0.29 | 1.45 | 7000 | 0.06 | 2.04 | 11.08 | 0.44 | 34.6 | |
| HBH0405MQ | 4.0 | 0.22 | 1.10 | 6000 | 0.04 | 1.53 | 8.86 | 0.35 | 28.3 | |||
| HBH0405LQ | 4.0 | 0.14 | 0.70 | 5000 | 0.03 | 1.02 | 5.27 | 0.21 | 19.5 | |||
| HBH0412HQ | Hydraulic | 12 | 9.0 | 0.13 | 1.56 | 7000 | 0.06 | 2.04 | 11.08 | 0.44 | 34.6 | |
| HBH0412MQ | 9.0 | 0.09 | 1.08 | 6000 | 0.04 | 1.53 | 8.86 | 0.35 | 28.3 | |||
| HBH0412LQ | 9.0 | 0.07 | 0.84 | 5000 | 0.03 | 1.02 | 5.27 | 0.21 | 19.5 | |||
| Bearing Type:S=Sleeve Bearing H=Hydraulic Bearing B=Two Ball Bearing C=One Ball One Sleeve Bearing | ||||||||||||
