254*89MM
254*89MM
  • 254*89MM

254*89MM

产品简介:

尺寸: 254*89mm
材质: 环保防火PBT UL 94V-0
工作电压: 110V 220V
轴承结构: 含油轴承,滚珠轴承
产品寿命: 3万小时,7万小时
输出功能: FG功能
运行温度: -10℃ ~70℃
贮存温度: -40℃ ~75℃
点击咨询
点击下载pdf

产品描述



254×89MM
Model Bearing Rated Voltage  Voltage Range Freq. Current Speed Air Flow Static Pressure Noise
Part NO. Type System VAC VAC Hz A RPM M3/min CFM mmH2O INH2O dBA
HAS254110HX W/T Sleeve 110 100-125 50/60 0.45/0.36 1380/1640 13.58/15.57 480/550 6.1/7.1 0.24/0.28 48/56
HAS254110MX W/T 100-125 50/60 0.32/0.28 1100/1240 10.75/12.74 380/450 3.0/4.1 0.12/0.16 41/45
HAB254110HX W/T Ball 100-125 50/60 0.45/0.36 1380/1640 13.58/15.57 480/550 6.1/7.1 0.24/0.28 48/56
HAB254110MX W/T 100-125 50/60 0.32/0.28 1100/1240 10.75/12.74 380/450 3.0/4.1 0.12/0.16 41/45
HAS254220HX W/T Sleeve 220 200-240 50/60 0.23/0.18 1380/1640 13.58/15.57 480/550 6.1/7.1 0.24/0.28 48/56
HAS254220MX W/T 200-240 50/60 0.17/0.15 1100/1240 10.75/12.74 380/450 3.0/4.1 0.12/0.16 41/45
HAB254220HX W/T Ball 200-240 50/60 0.23/0.18 1380/1640 13.58/15.57 480/550 6.1/7.1 0.24/0.28 48/56
HAB254220MX W/T 200-240 50/60 0.17/0.15 1100/1240 10.75/12.74 380/450 3.0/4.1 0.12/0.16 41/45
Bearing Type:S=Sleeve  Bearing   H=Hydraulic Bearing   B=Two Ball Bearing   C=One Ball  One Sleeve  Bearing
