| 75×75×30MM-1 | ||||||||||||
| Model | Bearing | Rated Voltage | Startup Voltage | Current | Power | Speed | Air Flow | Static Pressure | Noise | |||
| Part NO. | Function | System | VDC | VDC | A | W | RPM | M3/min | CFM | mmH2O | INH2O | dBA |
| HBS7512HY-1 | -A | Sleeve | 12 | 5.0 | 0.18 | 2.16 | 3500 | 0.29 | 10.08 | 16.66 | 0.66 | 40.6 |
| HBS7512MY-1 | 5.0 | 0.15 | 1.80 | 3000 | 0.24 | 8.62 | 11.41 | 0.45 | 37.0 | |||
| HBS7512LY-1 | 5.0 | 0.12 | 1.44 | 2500 | 0.21 | 7.37 | 7.54 | 0.30 | 33.3 | |||
| HBB7512VY-1 | -A | Ball | 5.0 | 0.43 | 5.16 | 5000 | 0.39 | 13.68 | 32.53 | 1.28 | 50.0 | |
| HBB7512EY-1 | -A | 5.0 | 0.36 | 4.32 | 4500 | 0.35 | 12.31 | 26.35 | 1.04 | 47.7 | ||
| HBB7512UY-1 | -A | 5.0 | 0.24 | 2.88 | 4200 | 0.33 | 11.74 | 24.74 | 0.97 | 45.3 | ||
| HBB7512HY-1 | 5.0 | 0.18 | 2.16 | 3500 | 0.29 | 10.08 | 16.66 | 0.66 | 40.6 | |||
| HBB7512MY-1 | 5.0 | 0.15 | 1.80 | 3000 | 0.24 | 8.62 | 11.41 | 0.45 | 37.0 | |||
| HBB7512LY-1 | 5.0 | 0.12 | 1.44 | 2500 | 0.21 | 7.37 | 7.54 | 0.30 | 33.3 | |||
| HBS7524HY-1 | -A | Sleeve | 24 | 12.0 | 0.20 | 4.80 | 3500 | 0.29 | 10.08 | 16.66 | 0.66 | 40.6 |
| HBS7524MY-1 | 12.0 | 0.12 | 2.88 | 3000 | 0.24 | 8.62 | 11.41 | 0.45 | 37.0 | |||
| HBS7524LY-1 | 12.0 | 0.10 | 2.40 | 2500 | 0.21 | 7.37 | 7.54 | 0.30 | 33.3 | |||
| HBB7524EY-1 | -A | Ball | 12.0 | 0.38 | 9.12 | 4500 | 0.35 | 12.31 | 26.35 | 1.04 | 47.7 | |
| HBB7524UY-1 | -A | 12.0 | 0.27 | 6.48 | 4200 | 0.33 | 11.74 | 24.74 | 0.97 | 45.3 | ||
| HBB7524HY-1 | -A | 12.0 | 0.20 | 4.80 | 3500 | 0.29 | 10.08 | 16.66 | 0.66 | 40.6 | ||
| HBB7524MY-1 | 12.0 | 0.12 | 2.88 | 3000 | 0.24 | 8.62 | 11.41 | 0.45 | 37.0 | |||
| HBB7524LY-1 | 12.0 | 0.10 | 2.40 | 2500 | 0.21 | 7.37 | 7.54 | 0.30 | 33.3 | |||
| Bearing Type:S=Sleeve Bearing H=Hydraulic Bearing B=Two Ball Bearing C=One Ball One Sleeve Bearing | ||||||||||||
