Product introduction:
| Size: | 25x25x07mm-2 |
|---|---|
| Material: | Environmental protection and fire protection PBT UL 94V-0 |
| Operating voltage: | 5V 12V |
| Bearing structure: | Oil Bearing Double Ball bearing |
| Product life: | 30,000 hours, 70,000 hours |
| Output function: | FG function RD function PWM function |
| Operating temperature: | -10℃ ~70℃ |
| Storage temperature: | -40℃ ~75℃ |
| 25*25*07MM-2 | ||||||||||||
| Model | Bearing | Rated Voltage | Startup Voltage | Current | Power | Speed | Air Flow | Static Pressure | Noise | |||
| Part NO. | Function | System | VDC | VDC | A | W | RPM | M3/min | CFM | mmH2O | INH2O | dBA |
| HDH2505HQ-2 | Hydraulic | 5 | 4.5 | 0.15 | 0.75 | 13000 | 0.07 | 2.31 | 5.45 | 0.21 | 25.2 | |
| HDH2505MQ-2 | 4.5 | 0.10 | 0.50 | 10000 | 0.05 | 1.83 | 3.04 | 0.12 | 18.1 | |||
| HDH2505LQ-2 | 4.5 | 0.07 | 0.35 | 7000 | 0.03 | 0.95 | 1.36 | 0.05 | 17.5 | |||
| HDH2512HQ-2 | 12 | 9.5 | 0.12 | 1.44 | 13000 | 0.07 | 2.31 | 5.45 | 0.21 | 25.2 | ||
| HDH2512MQ-2 | 9.5 | 0.08 | 0.96 | 10000 | 0.05 | 1.83 | 3.04 | 0.12 | 18.1 | |||
| HDH2512LQ-2 | 9.5 | 0.06 | 0.72 | 7000 | 0.03 | 0.95 | 1.36 | 0.05 | 17.5 | |||
| Bearing Type:S=Sleeve Bearing H=Hydraulic Bearing B=Two Ball Bearing C=One Ball One Sleeve Bearing | ||||||||||||
