Product introduction:
| Size: | 40x40x28mm-2 |
|---|---|
| Material: | Environmental protection and fire protection PBT UL 94V-0 |
| Operating voltage: | 5V 12V 24V |
| Bearing structure: | Oil bearing Double ball bearing |
| Product life: | 30,000 hours 70,000 hours |
| Output function: | FG function RD function PWM function |
| Operating temperature: | -10℃ ~70℃ |
| Storage temperature: | -40℃ ~75℃ |
| 40×40×28mm-2 | ||||||||||||
| Model | Bearing | Rated Voltage | Startup Voltage | Current | Power | Speed | Air Flow | Static Pressure | Noise | |||
| Part NO. | Function | System | VDC | VDC | A | W | RPM | M3/min | CFM | mmH2O | INH2O | dBA |
| HDB0412HB-2 | Ball | 12 | 6.0 | 1.00 | 12.0 | 21000 | 0.65 | 22.89 | 56.06 | 2.21 | 63.9 | |
| HDB0412MB-2 | 6.0 | 0.75 | 9.00 | 19000 | 0.60 | 21.26 | 49.05 | 1.93 | 58.1 | |||
| HDB0412LB-2 | 9.0 | 0.50 | 6.00 | 17000 | 0.53 | 18.78 | 39.02 | 1.54 | 55.8 | |||
| HDB0412HB-2 | Ball | 24 | 18.0 | 0.80 | 19.20 | 21000 | 0.65 | 22.89 | 56.06 | 2.21 | 63.9 | |
| HDB0412MB-2 | 18.0 | 0.55 | 13.20 | 19000 | 0.60 | 21.26 | 49.05 | 1.93 | 58.1 | |||
| HDB0424LB-2 | 18.0l | 0.30 | 7.20 | 17000 | 0.53 | 18.78 | 39.02 | 1.54 | 55.8 | |||
| Bearing Type:S=Sleeve Bearing H=Hydraulic Bearing B=Two Ball Bearing C=One Ball One Sleeve Bearing | ||||||||||||
