Product introduction:

Size: 60x60x10mm-2
Material: Environmental protection and fire protection PBT UL 94V-0
Operating voltage: 5V 12V 24V
Bearing structure: Hydraulic bearings, ball bearings
Product life: 40,000 hours,70,000 hours
Output function: FG function  RD function PWM function
Operating temperature: -10℃ ~70℃
Storage temperature: -40℃ ~75℃
Click for Inqueries
Click to Download pdf

60x60x10mm-2
Frame Size(mm) Part NO. Function System VDC VDC A W RPM M3/min CFM mmH2O INH2O dBA
60x60x10mm-2 HYB0612HG-2   Sleeve  /Bal 12 6.0 0.22 2.64 4000 0.43 15.09 2.31 0.09 29.2
HYB0612MG-2 6.0 0.18 2.16 3500 0.38 13.29 1.81 0.07 26.8
HYB0612LG-2 6.0 0.16 1.92 3000 0.31 10.84 1.26 0.05 23.0
