产品描述
| 20×20×06MM | ||||||||||||
| Model | Bearing | Rated Voltage | Startup Voltage | Current | Power | Speed | Air Flow | Static Pressure | Noise | |||
| Part NO. | Function | System | VDC | VDC | A | W | RPM | M3/min | CFM | mmH2O | INH2O | dBA |
| HDS0205HK | -A | S | 5 | 4.0 | 0.22 | 1.10 | 15000 | 0.03 | 1.17 | 3.93 | 0.15 | 14.5 |
| HDS0205MK | -A | 4.0 | 0.17 | 0.85 | 12000 | 0.03 | 0.91 | 2.51 | 0.10 | 11.7 | ||
| HDS0205LK | -A | 4.0 | 0.12 | 0.60 | 9000 | 0.02 | 0.73 | 1.43 | 0.06 | 8.3 | ||
| HDS0212HK | -A | S | 12 | 6.0 | 0.11 | 1.32 | 15000 | 0.03 | 1.17 | 3.93 | 0.15 | 14.5 |
| HDS0212MK | -A | 6.0 | 0.10 | 1.20 | 12000 | 0.03 | 0.91 | 2.51 | 0.10 | 11.7 | ||
| HDS0212LK | -A | 6.0 | 0.08 | 0.96 | 9000 | 0.02 | 0.73 | 1.43 | 0.06 | 8.3 | ||
| Electric Strength | 5mA max at 1500VAC for 1 min between lead wire and frame | |||||||||||
| Insulation Resistance | 10M ohm between lead wire and frame(DC 500V) | |||||||||||
| Life Expectancy(Ball bearing) | 50000hrs min at 40 degree C/L10 relative humidity 65%+/-20% | |||||||||||
| Life Expectancy(Hydraulic bearing) | >40000hrs min at 40 degree C/L10 relative humidity 65%+/-20% | |||||||||||
| Operation Temperature | -10~75 degree C(+14~167 degree F),normal; -10~90 degree C(+14~194 degree F), specification | |||||||||||
| Storage Temperature | Storage Temperature: -40~75 degree C(-40~167 degree F) | |||||||||||
| Protection | Motor protection and polarity protection | |||||||||||
| Lead wire | UL1571 AWG28,30; UL1007 AWG24,26; UL1061 AWG26 | |||||||||||
| Plastic Material | Motor protection and polarity protection | |||||||||||
