12012025MM
Model		Bearing	Rated Voltage	Startup Voltage	Current	Power	Speed	Air Flow		Static Pressure		Noise
Model		Bearing	Rated Voltage	Startup Voltage	Current	Power	Speed	Air Flow		Static Pressure		Noise
Part NO.	Function	System	VDC	VDC	A	W	RPM	M³/min	CFM	mmH₂O	INH₂O	dBA
HBS1212HA		SLEEVE	12	9.5	0.45	5.40	2500	1.51	53.32	13.48	0.53	45.0
HBS1212MA				9.5	0.40	4.80	2000	1.36	47.92	11.35	0.45	41.2
HBS1212LA				9.5	0.32	3.84	1500	1.10	38.96	9.51	0.37	34.8
HBB1212HA		BALL		9.5	0.45	5.40	2500	1.51	53.32	13.48	0.53	45.0
HBB1212MA				9.5	0.40	4.80	2000	1.36	47.92	11.35	0.45	41.2
HBB1212LA				9.5	0.32	3.84	1500	1.10	38.96	9.51	0.37	34.8
HBS1224HA		SLEEVE	24	12.0	0.30	7.20	2500	1.51	53.32	13.48	0.53	45.0
HBS1224MA				12.0	0.25	6.00	2000	1.36	47.92	11.35	0.45	41.2
HBS1224LA				12.0	0.20	4.80	1500	1.10	38.96	9.51	0.37	34.8
HBB1224HA		BALL		12.0	0.30	7.20	2500	1.51	53.32	13.48	0.53	45.0
HBB1224MA				12.0	0.25	6.00	2000	1.36	47.92	11.35	0.45	41.2
HBB1224LA				12.0	0.20	4.80	1500	1.10	38.96	9.51	0.37	34.8
Bearing Type:S=Sleeve Bearing H=Hydraulic Bearing B=Two Ball Bearing C=One Ball One Sleeve Bearing

120x120x25mm

DC-轴流风扇
